16A 250V Thailand Type O Plug 3-Pin Power Cord match to H05VV-F 3G1.0mm² PVC cable
- Male Plug Type : Type O
- Female end Type : Stripped or Customized
- Rated Current & Voltage : 16A 250V
- Rated Temperature: 70℃
- Conductor：Stranded pure bare copper
- Insulation ： PVC or Rubber
- Jacket : PVC or Rubber
- RoHS & Reach : Approval
- Certificate : TUV,IEC
Description
16A 250V Thailand Type O Plug 3-Pin Plug Power Cord match to H05VV-F 3G1.0mm² PVC cable
• Used in: Type O is used exclusively in Thailand
• The type O socket and plug, rated at 16 amps, are the official standard in Thailand. The plug system was designed in 2006, but its use is not widespread as yet. It is currently gradually being phased in. The standard is described in TIS 166-2549.
• Type O consists of two power pins and an earth pin, which are round and have a 4.8 mm diameter. The power pins measure 19 mm in length, they have 10 mm long insulated sleeves and their centers are spaced 19 mm apart.
• Certificate : TUV,IEC
| Plug Type | Standard | Applicable Cord | Certificate | |
| Plug Type O 16A 250V |
TIS 166-2549 |
H03VV-F 3G0.5~0.75mm² H05VV-F 3G0.75~2.5mm² H05RN-F 3G0.75~1.0mm² |
TUV IEC |
|
