UL3385 XLPE Insulated AC300V 105℃ FT2 Flame Test 14AWG Electrical Hook up Cable

Description

UL3385 XLPE Insulated AC300V 105℃ FT2 Flame Test 14AWG Electrical Hook up Cable

• UL certificate, Compliant with UL758 Standard

• Rating : 105 deg C, 300 Vac, Horizontal flame.

•  Conductor : 32 AWG – 10 AWG, solid or stranded.

• Insulation : Extruded XLPE, 15 mils minimum average thickness, 13 mils minimum thickness at any point

• Shield : Optional.

• Jacket : Optional, except when shield is used. Extruded PVC, 15 mils minimum average thickness, 12 mils minimum thickness at any point.

• Covering : Optional, treated or untreated braid.

• Use : Internal wiring of appliances, tags may indicate the following: 600 Volts Peak – For Electronic Use Only.

Applications
UL3385 – XLPE Hook-up & Lead Wire

• Internal wiring of household appliances such as refrigerators, air conditioners, ovens, microwave ovens, and washing machines

• Motor lead wires for pumps, compressors, fans, and other industrial motors

• Wiring inside lighting equipment, including ballasts and lighting fixtures

• Internal wiring for transformers, power supplies, power modules, and electronic devices

• Internal wiring for industrial control panels, automation equipment, and instrumentation/electronic equipment

UL3385 is suitable for fixed internal wiring environments requiring high-temperature resistance, mechanical durability, and chemical resistance.
